SIMPSON LS70Z 2-1/2"X2-1/2"X7-7/8" SKEWABLE ANGLE ZMAX

Delivery Options
Pick Up at Branch

Shopping the Augusta branch

The LS connector is a cost-effective method for connecting roof rafters to hip rafters. The durable design and fastening options of these load-rated skewable angles make them an ideal option compared to field-fabricated clip angles. The LS has well-defined fastener locations, and testing ensures that the tabulated load values account for connection eccentricities.

Additional Details

  • Product Code: LS70Z
  • Manufacturer Code: LS70Z
  • UPC: 044315665301
  • Weight: 1
  • Length: 6-3/8 in.
  • Assembled Width: 3.84099 in.
  • Assembled Height: 6.375 in.
  • Assembled Depth: 1.59099 in.
  • Install With: Install with 10d common nails or #9 x 1-1/2 in. Strong-Drive® SD screws
  • Packaging Quantity: 1
  • Packaging Type: Individual Item
  • Coating: ZMAX®
  • Color: None
  • Gauge: 18
  • General utility-reinforcing angles with multiple uses
  • Field-adjustable angles from 0° to 135° allow for attaching members intersecting at angles
  • Perfect angle series for many household repairs and DIY projects
  • Made from 18-gauge steel
  • ZMAX galvanization offers extra corrosion resistance for exterior and treated-wood applications
